Product Details
LSP01-3A Single Channel Syringe Pump
Single-channel syringe pump which only have infusion mode. These pumps are very easy to operate including a LCD display with rotary coded switch and a simple membrane keypad.
Flow rates：0.001μl-43.349ml/min
Max. Number of Channels：1
Features
- Mainly used in Lab applications
- Excellent EMC performance, ESD≥Level IV (IEC 61000-4-2)
- The acceptable syringe specification is from 10 μL to 60 mL
- Suitable for high accuracy and small flow rate liquid transferring
Specification
Syringe pump：LSP01-3A
No. of Syringes：1
Advance per Mircostep：1/16step: 0.156 μm
Infusion Volumn per Microstep：0.13 μL (60 mL BD Syringe)
Syringe Size：10 μL - 60 mL
Max. Linear Rate：65 mm/min
Min. Linear Rate：5μm/min
Flow Rate：0.831 nL/min - 54.155 ml/min
Working Mode：Infusion
Linear Force：> 9 kgf
Max. Step Rate：6933 (1/16step)/ sec
Min. Step Rate：16 (1/16 step) /30 sec
Accuracy：≤ 0.5% error in the condition of > 30% of max. infusion distance
Setting Mode：Rotary coded switch and membrane keypad
Display：128 x 64 graphic LCD
Power：AC 196V-240V/20W
Operating Condition：Temperature 5 °C - 40 °C Relative humidity < 80 %
Dimensions：280 × 210 × 140 mm
Weights：3.6 kg
